Smart Wireless 4G/WIFI/BT GPRS NFC Handheld Touch Screen EFT
Android POS Terminal With Fingerprint
Products
Samples or trial order, we provide latest inventory products, for
bulk requirements, we need 3 weeks to produce. We will have all
products inspected before shipping, and we provide a sound packing
in case of damage during delivery.
Tech Support
Tech support and free sdk provided regardless of quantities. Remote
compile or free demo and demo video and code available as
requested. Customized application may charge according to detailed
functions.
Logistics
Express, by air, by sea. Delivery may take 3-15 days after receipt
of payment. Most areas, we send goods via DHL, TNT, UPS, Fedex,
EMS. We can also arrange special line for Russia, Iran, etc.
| WCT-S8 Android POS Configuration |
| Type | Product Spec |
| Platform | Processor | MTK MT8735 ( 4-Core ARM Cortex-A53,1.3GHz ) |
| RAM | 1GB / 2GB LPDDR3 |
| FLASH | 8GB / 16GB EMMC |
| OS | Android 7.0 Security Payment OS |
| Security Processor | MAXIM MAX32555 (DeepCover Secure microcontroller) |
| Wireless | Wireless Standard | LTE-FDD/TDD-LTE/TDS-CDMA/WCDMA/CDMA2000/EDGE/GPRS |
| 4G | LTE-FDD : B1/B3/B8 (TBD) |
| TDD-LTE : B38/B39/B40/B41 |
| 3G | UMTS/HSPA/HSPA+/DC-HSPA+ : B1/B8 |
| TDS-CDMA : B34/B39 |
| EVDO : BC0 |
| 2G | EDGE/GPRS : B3/B8 |
| WLAN | 2.4GHz ISM 2402MHz~2482MHz |
| BT 4.1 LE | 2.4GHz ISM 2402MHz~2480MHz |
| USIM | Card Slots | 4 PSAM slots, 2 SIM slots |
| GPS | GPS | GPS, GLONASS |
| LCD and Touch Panel | LCD Pixels | 720*1280 IPS |
| LCD | 5.5 inch |
| Touch Panel | G+F+F, Capacitive Color Touch,Multi Touch, signature capable, video
capable |
| Keypad | Physical key | Power ON/OFF, Volumn up, Volumn down. |
| Virtual Keypad | Home Key, Function key, Numeric Keys. |
| Audio | Speaker | 1 W x 1 |
| Microphone | Voice input |
| USB | USB Standard | USB Type C 2.0 |
| Other | Charge Battery, OTG support |
| Camera | REAR | 8Mega Pixels, CMOS, AF, QR/2D barcode, JPEG picture, Video. |
| FRONT | 2Mega Pixels, CMOS, JPEG picture, Video. |
| NFC | Standard | ISO14443 type A/B ( ISO 18092 NFC, ISO/IEC 14443&7816, FeliCa
support ) |
| Spectrum | 13.56MHz |
| IC card | Contactless Card | NFC 13.56 MHz, Support ISO/IEC 14443 Type A&B, ISO/IEC
14443&7816 |
| EMV card | Smart Card | EMV & PBOC Compliant |
| MSR | Magnetic Card | ISO 7810, 7811, 7813; Triple Track, Bi-Directional; swipe speed
10cm/sec - 100cm/sec. |
| Battery | Battery type | Li-ion polymer battery |
| Capacity | 3.7V, 5800mAh |
| Charger | 5V/2A |
| Certification | ICC | EMV contact L1 / PBCO L1 |
| EMV contact L2 / PBOC L2 |
| NFC | EMV contactless L1 / qPBOC L1 |
| EMV contactless L2 / qPBOC L2 |
| Security | PCI 5.0 |
| UPTS 2.0 |
| Operating environment | Temperature | -5 to +50 °C |
| Relative humidity | 10 % to 85 % RH |
| Storage environment | Temperature | -10 to +60 °C |
| Relative humidity | 10 % to 90 % RH |
| Size and Weigt | Dimension and Weight | 203mm*85mm*53mm, 480g with battery |
| Micro Printer | Printing method | Thermal-line dot method |
| Paper | Thermal roll paper (standard) 57*40 mm |
| Effective Printing area | 48mm |
| Speed | Maximum 70mm/sec(480 dot line/sec) |
| Printing resolutions | 8 dots/mm |
| Character | 12*24dots and 24*48 dots |
| Number of columns | 32columns/line |
| Printing head life | Pulse resistance:100 million pulses/dot (under our standard
conditions); |
| Abrasion resistance: paper traveling distance 50km (print ratio:25%
or less) |
FAQ:
1. About Price:
The price is negotiable. It can be changed according to your
quantity or package. When you are making an inquiry, please let us
know the quantity you want.
2. About Sample:
Sample is Free, but the air freight is collected or you pay us the
cost in advance.
3. About language and operation system:
Our printers support 48 different languages include English,
Russian, Spanish and so on. It backups IOS, Android, Windows,
Linux, Oppos operation systems.
4. About warranty:
Each printer will have one year (12 months) warranty. Free
components will be offered for repair in warranty period, if the
issue caused by non-artificial damages.
5. About MOQ:
No MOQ limitation for the standard products, but the unit price is
different. For customized production, you can discuss the MOQ with
our sales rep.
Company Information:
Wisecard (a WiseGroup company) is a global solution provider that
has been providing innovative payment and secure solutions to
financial institutions, government entities and telco operators
worldwide.
Wisecard have been providing EMV smart card, EMV biometric card,
EMV perso software, card issuance, EMV embossers, Smart POS
machine, Android POS, POS terminals, smart banking, smart teller
machine, kiosk, vending machine, biometric POS, Hardware Secure
Module, mobile payment platform, private label card solution,
prepaid card solution, card management system to partners in more
than 60 countries worldwide. Wisecard’s product suite empower large
global financial institutions and government sectors as well as
small to medium sized retail banks.
Wisecard solutions are adapting to the highest and latest secure
standard, and the solutions have been fully tested and certified by
international test labs, like FBI, STQC, EMV, PCI DSS, PA DSS,
VISA, MasterCard, China UnionPay, JCB, AmEx, Discover, RuPay and
etc.
Notes: FBI, STQC, EMV, PCIDSS, PADSS, Visa, MasterCard, China
UnionPay, JCB, AmEx, Discover, RuPay is a registered trademark. All
trademarks referenced here are the property of the respective
owners.
